1) Technical characteristics
1. The transmission mode adopts the belt drive at the lower side and the upper cover is automatically folded. The upper and lower "one letter" box sealing is completed at one time (wiring or single machine operation is available). The machine platform includes a 90 degree steering box pushing mechanism. The four corner "I" type box sealing is completed at one time.
2. The upper and lower cartons and the four corners are sealed.
3. Adjust the height and width manually when changing specifications.
4. The sealing machine adopts belt conveyor, power drum and non power drum.
5. Worktable can be customized according to customer requirements.
6. Electrical configuration: French "Schneider" is used as the contactor, Taiwan "Yadeke" as the pneumatic component, and Taiwan "as the motor.
7. The carton is 340mm-700mm long, 120mm-500mm wide and 120mm-600mm high. (Customizable)
2) Scope of application and functional characteristics
1. This product is suitable for carton packaging of food, pharmaceutical and chemical products, electronic products, printed products, toys, furniture, bathroom lighting and other products, such as carton, carton, door panel, glass, and hardware frame. This model is mainly used for carton packaging.
2. Suitable for kraft paper tape and BOPP tape.
Equipment Model: XK-FX500T
Conveying Mode: Belt+roller
Packaging Speed: 360~600 cases/hour
Noise Level: Maximum 80DBA
Power Consumption: Max. 1KW
Air Source: 6kgf/cm ² 100nl/min
Power Supply (optional): 220V/50Hz/60Hz/1Ph 380V/50Hz/60Hz/3Ph
Boundary Dimension: 3950mm long/2900mm wide/1600mm high
Machine Weight: 700KG
