Fastener Weighing Packaging Machine

HOME > PRODUCTS > Vertical Packaging Machine > Fastener Weighing Packaging Machine

Recommended

Replay

Recommended

Lamination Film Packaging Machine Semi-Automatic CPP/OPP/PE XK-B860X

Automatic Counting Coding Screw Packaging Machine XK-B861

Automatic Single Vibrator Bowl Screw Packaging Machine XK-B861

Convergent Chain Bucket Type Automatic Accessories Packaging Machine

XK-B861T One Vibrator Bowl Weighing Complement Packaging Machine

XK-B862 Xingke 2 Items Mixing Products Packing Continuous Packages Packaging Machine-副本.

(1) Technical features

1. The vibrating plate automatically arranges materials, automatically counts, automatically fills, automatically packs, seals, and counts output.

2. The intelligent temperature control system is adopted, the temperature control is stable, and the temperature can be adjusted according to the needs.

3. The length of the packaging bag is adjustable, the total number of packaging is adjustable, and the set number of times is automatically alarmed.

4. After packaging, the bag shape is uniform, regular, beautiful and firm. It can also be equipped with expansion equipment such as coding machine, check weighing machine, labeling machine and elevator, and other materials can be mixed and packaged manually in the spare space of the equipment.

(2) Scope of application and functional characteristics

1.This product is suitable for automatic packaging of single materials, such as screws, nuts, flat pads, spring pads, toys, standard parts, etc. After the vibration plate is automatically counted, the product is filled into the automatic packaging of the molding machine, and the climbing belt is added to connect other machines to put materials into the vibration plate.

2. It is suitable for "OPP/CPP/composite film" as sealing material.

SEND INQUIRY NOW

Product Details

Company Introduction

Xingke is the sole proprietor of Zhongshan Xingke Automation Equipment Co., Ltd.. We are an ISO 9001 certified company Pioneer in manufacturing of Packaging Machine at a larger range in China, with strict attention to quality standards for defect free products, high durability and its robust construction. The complete range of products are thoroughly checked and tested to threshold levels to ascertain its reliability.

Product Introduction

Equipment mode	XK-B861T	Counting method	fiber counting/stopping and discharging
Bag siz	width 40-140 within 200 length	Packing speed	1-60 bags/min
Seal shap	stripe, back seal/trilateral seal (normally back seal)	Voltage power	220V/50Hz P≈0.6KW
Air source requirement	0.4-0.8MPA	Bag mouth shap	figure cutter tooth shape
Dimensions	length 1300mm/width 1020mm/height 1500mm	Weight	about 150KG

Product Introduction

Company Introduction

Established in the year 2017, we, Zhongshan Xingke Automation Equipment Co., Ltd., are engaged in manufacturer, supplier, exporter and trader of Packaging Machine. Our range of products encompasses Vertical Packaging Machine,Horizontal Packaging Machine,Sealing And Cutting Packaging Machine,Auxiliary Packaging Equipment. We are backed by a diligent team of professionals, which helps us in offering an impeccable array of products to the clients. These experts utilize their vast industry experience and in-depth knowledge to formulated international quality standard products. Moreover, the quality controllers of our team stringently test the final products on certain parameters of quality, so as to ensure their effectiveness.

Basic Information

Year Established

--
Business Type

--
Country / Region

--
Main Industry

--
Main Products

--
Enterprise Legal Person

--
Total Employees

--
Annual Output Value

--
Export Market

--
Cooperated Customers

--

Lamination Film Packaging Machine Semi-Automatic CPP/OPP/PE XK-B860X

1) Technical characteristics1. Automatic filling, automatic packaging, sealing function, output counting.2. Adopt intelligent temperature control system, stable temperature control, temperature adjustable according to needs.3. The length of the packaging bag is adjustable, the total number of packaging is adjustable, and the alarm is automatically triggered when the set number is reached.4. After packaging, the bag shape is uniform, regular, beautiful, and firm. And expansion equipment such as coding machine, check weighing, labeling machine, hoist, etc. can also be added.2) Scope of application and functional characteristics1. This product is suitable for products with long, irregular product shapes, large length and width ratios. And suitable for products that have extremely high surface requirements such as electroplating, spray painting, paint and other process treatments, such as electroplated process plastic products, toys, bolts, screwdrivers, data cables, etc., are manually put in materials. And the belt conveys the materials to the forming machine, and automatically fills the packaging.2. Suitable for "OPP/CPP/lamination film" as a sealing material.
Automatic Counting Coding Screw Packaging Machine XK-B861

1) Technical characteristics1. Vibrator bowl automatically arranges materials, automatic counting, automatic filling, automatic packaging, sealing function, and output counting.2. Adopt intelligent temperature control system, stable temperature control, temperature adjustable according to needs.3. The length of the packaging bag is adjustable, the total number of packaging is adjustable. Automatic alarm when the set number is reached.4. After packaging, the bag shape is uniform, regular, beautiful, and firm. And expansion equipment such as coding machine, check weighing, labeling machine, hoist, etc. can also be added.2) Scope of application and functional characteristics1. This product is suitable for automatic packaging of single materials, such as screws, nuts, flat washers, spring washers, toys, standard parts, etc. After the vibrator bowl is automatically counted, the product is filled into the automatic packaging of the former, and the spare equipment can also be used space artificially puts other materials in mixed packaging.2. Suitable for "OPP/CPP/lamination film" as a sealing material.
Automatic Single Vibrator Bowl Screw Packaging Machine XK-B861

1) Technical characteristics1. Vibrator bowl automatically arranges materials, automatic counting, automatic filling, automatic packaging, sealing function, and output counting.2. Adopt intelligent temperature control system, stable temperature control, temperature adjustable according to needs.3. The length of the packaging bag is adjustable, the total number of packaging is adjustable. Automatically alarm when the set number is reached.4. After packaging, the bag shape is uniform, regular, beautiful, and firm. And expansion equipment such as coding machine, check weighing, labeling machine, hoist, etc. can also be added.2) Scope of application and functional characteristics1. This product is suitable for automatic packaging of single materials, such as screws, nuts, flat washers, spring washers, toys, standard parts, etc. After the vibrator bowl is automatically counted, the product is filled into the automatic packaging of the forming machine, and the spare equipment can also be used space artificially puts other materials in mixed packaging.2. Suitable for "OPP/CPP/lamination film" as a sealing material.
Convergent Chain Bucket Type Automatic Accessories Packaging Machine

XK-B862T（Double Vibrator Bowl Convergent Chain Bucket Type Automatic Hardware Accessories Screw Packaging Machine）.1) Technical characteristics1.Vibrator bowl automatically arranges materials, automatic counting, automatic filling, automatic packaging, sealing function, and output counting.2. Adopt intelligent temperature control system, stable temperature control, temperature adjustable according to needs.3. The length of the packaging bag is adjustable, the total number of packaging is adjustable, and automatic alarm when the set number is reached.4. After packaging, the bag shape is uniform, regular, beautiful, and firm. And expansion equipment such as coding machine, check weighing, labeling machine, hoist, etc. can also be added.2) Scope of application and functional characteristics1. This product is suitable for automatic mixing or separate packaging of the following materials, such as screws, nuts, flat washers, spring washers, toys, standard parts, etc. This product uses a chain bucket to drive the material box to rotate, and the vibrator bowl automatically counts materials put the product into the material box, the chain bucket will fill the product into the automatic packaging of the forming machine, and use the free space of the equipment to manually put other materials in mixed packaging.2. Suitable for "OPP/CPP/lamination film" as a sealing material.
